Silicon-Germanium Strained Layers and Heterostructures: Semi-conductor and semi-metals series

Willander, M.; Jain, Suresh C.

In stock
Regular price 88.750 KD inc. VAT
License
Table of contents
  • Cover
  • Contentsv
  • Preface to the first editionxi
  • Preface to the second editionxiii
  • Chapter 1. Introduction1
  • 1.1 Development of SiGe technology1
  • 1.2 Commercial production of SiGe devices3
  • 1.3 Landmarks in the development of SiGe devices5
  • Chapter 2. Strain, stability, reliability and growth9
  • 2.1 Strain and dislocations9
  • 2.2 Strain and dislocation energies12
  • 2.3 Critical thickness17
  • 2.4 Stability of strained layers22
  • 2.5 Stresses in quantum structures29
  • 2.6 Poly-SiGe and poly-SiGeC films33
  • 2.7 Growth of strain relaxed layers35
  • Chapter 3. Mechanism of strain relaxation41
  • 3.1 Introduction41
  • 3.2 Propagation of dislocations41
  • 3.3 Nucleation, multiplication and blocking47
  • 3.4 Strain relaxation54
  • 3.5 Summary58
  • Chapter 4. Strain, growth, and TED in SiGeC layers61
  • 4.1 Introduction61
  • 4.2 Strain and Growth of Si1–x–yGexCy layers62
  • 4.3 Thermal diffusion73
  • 4.4 TED and its suppression by carbon79
  • 4.5 Modelling of TED in Si1–x–yGexCy layers84
  • 4.6 Conclusion and summary90
  • Chapter 5. Bandstructure and related properties91
  • 5.1 Effect of strain on bandstructure91
  • 5.2 Effective Density of States and Fermi energy98
  • 5.3 Bandgap narrowing due to heavy doping101
  • 5.4 Mobility105
  • 5.5 Electrical properties of SiGeC films116
  • 5.6 Optical properties of unstrained alloys118
  • 5.7 Optical studies of strained layers124
  • 5.8 Optical studies of quantum wires and dots134
  • 5.9 Superlattices (SLs)140
  • Chapter 6. Heterostructure Bipolar Transistors147
  • 6.1 Introduction147
  • 6.2 Design149
  • 6.3 Technology154
  • 6.4 DC performance of SiGe HBTs161
  • 6.5 AC characteristics of the HBTs165
  • 6.6 Optimization of BVceo, ft and fmax169
  • 6.7 HBTs with SiGeC base-layers178
  • 6.8 Noise183
  • 6.9 Circuit applications188
  • 6.10 Summary192
  • Chapter 7. FETs and other devices195
  • 7.1 Ge channel MOS transistors195
  • 7.2 Strained layer p-channel MOSFETs196
  • 7.3 Strained layer n-channel MOSFETs202
  • 7.4 Modulation doped Field Effect Transistors206
  • 7.5 Strained-layer MOSFETs on insulator212
  • 7.6 High-k gate-insulators215
  • 7.7 MOSFETs containing Si1-x-yGexCy alloys218
  • 7.8 Ultra-shallow junctions219
  • 7.9 Application of SiGe to ultrashallow junctions226
  • 7.10 Resonant tunnelling diodes231
  • 7.11 Photodetectors, waveguide switch and laser236
  • Bibliography243
  • Index281
  • Contents of Volumes287
Book details
  • Vendor Elsevier S & T
  • SKU 9780127521831
  • ISBN-13 9780080541020
  • Author Willander, M.; Jain, Suresh C.
  • Edition 2nd
  • Category Technology & Engineering
  • Subject Materials Science

Do you have questions about this book?

Ask an expert!

The study of Silicone Germanium strained layers has broad implications for material scientists and engineers, in particular those working on the design and modelling of semi-conductor devices.

Since the publication of the original volume in 1994, there has been a steady flow of new ideas, new understanding, new Silicon-Germanium (SiGe) structures and new devices with enhanced performance. Written for both students and senior researchers, the 2nd edition of Silicon-Germanium Strained Layers and Heterostructures provides an essential up-date of this important topic, describing in particular the recent developments in technology and modelling.

* Fully-revised and updated 2nd edition incorporating important recent breakthroughs and a complete literature review
* The extensive bibliography of over 400 papers provides a comprehensive and coherent overview of the subject
* Appropriate for students and senior researchers
